TSE-95D
HS
The screw elements and kneading blocks are designed by preciseprocessed, agile combination, with interchangeability, which can fufil efficient sel-cleaning, transmission, compoudning, presure-forming, etc. The screw is made of high tool steel 38 CrMoALA or W6Mo5C4V3 by special heat-treatment, which is prossessed with high corrosion-resistant and high functions.
Engineer plastic generally means SAN, ABS, PET, PBT, POM, PMMA, PA6, PA66, PC and all reinforced and modified polymers used in injection and extrusion applications.
Applications:automotive, electrical, blow moulding, film and pipe extrusion, fiber, etc.
Processing methods: short fiber reinforce compounding and long-fiber thermoplastic (LFT).
Name: Twin screw plastic pelletizer machine | |
Diameter: 93mm | L/D:32-64 |
Motor Power: 400-450kw | Screw rotary: 600-800r/min |
Torque: 5.3N.m | Color:customized |
Package:Wooden case or wooden pallet | Voltage:220V,380V,415V |
The twin-screw extrusion machine offers high efficiency, strong mixing capability, and precise control for processing various plastic materials. It ensures uniform extrusion, stable performance, and wide application in compounding, granulation, and recycling.
Model | Diameter (mm) | L/D | Rotary (r/min) | Power (kw) | Torque (N.m) | T/N3 | Capacity (kg/h) |
TSE-20 | 22 | 32-44 | 600 | 5.5 | 43 | 7.5 | 0.5-10 |
TSE-30 | 31 | 32-48 | 600 | 15 | 119 | 6.7 | 5-40 |
TSE-40 | 41 | 32-52 | 600 | 30 | 239 | 5.8 | 90-150 |
TSE-50 | 50.5 | 32-52 | 500 | 55 | 430 | 5.4 | 135-270 |
TSE-65 | 62.4 | 32-64 | 600 | 90 | 716 | 5.1 | 200-300 |
TSE-75 | 71 | 32-64 | 600 | 132 | 1050 | 4.8 | 350-550 |
TSH-75 | 71 | 32-64 | 600 | 200-250 | 1365 | 7.6 | 600-9000 |
TSE-95 | 93 | 32-64 | 600 | 315 | 2506 | 5.3 | 800-1200 |
The screw elements and kneading blocks are designed by preciseprocessed, agile combination, with interchangeability, which can fufil efficient sel-cleaning, transmission, compoudning, presure-forming, etc. The screw is made of high tool steel 38 CrMoALA or W6Mo5C4V3 by special heat-treatment, which is prossessed with high corrosion-resistant and high functions.
Engineer plastic generally means SAN, ABS, PET, PBT, POM, PMMA, PA6, PA66, PC and all reinforced and modified polymers used in injection and extrusion applications.
Applications:automotive, electrical, blow moulding, film and pipe extrusion, fiber, etc.
Processing methods: short fiber reinforce compounding and long-fiber thermoplastic (LFT).
Name: Twin screw plastic pelletizer machine | |
Diameter: 93mm | L/D:32-64 |
Motor Power: 400-450kw | Screw rotary: 600-800r/min |
Torque: 5.3N.m | Color:customized |
Package:Wooden case or wooden pallet | Voltage:220V,380V,415V |
The twin-screw extrusion machine offers high efficiency, strong mixing capability, and precise control for processing various plastic materials. It ensures uniform extrusion, stable performance, and wide application in compounding, granulation, and recycling.
Model | Diameter (mm) | L/D | Rotary (r/min) | Power (kw) | Torque (N.m) | T/N3 | Capacity (kg/h) |
TSE-20 | 22 | 32-44 | 600 | 5.5 | 43 | 7.5 | 0.5-10 |
TSE-30 | 31 | 32-48 | 600 | 15 | 119 | 6.7 | 5-40 |
TSE-40 | 41 | 32-52 | 600 | 30 | 239 | 5.8 | 90-150 |
TSE-50 | 50.5 | 32-52 | 500 | 55 | 430 | 5.4 | 135-270 |
TSE-65 | 62.4 | 32-64 | 600 | 90 | 716 | 5.1 | 200-300 |
TSE-75 | 71 | 32-64 | 600 | 132 | 1050 | 4.8 | 350-550 |
TSH-75 | 71 | 32-64 | 600 | 200-250 | 1365 | 7.6 | 600-9000 |
TSE-95 | 93 | 32-64 | 600 | 315 | 2506 | 5.3 | 800-1200 |
